UL21686 TPU Curly Cable 28AWG 13C OD6.0mm VW-1 Matt Black L=300mm 80C 30V

Name: UL21686 TPU Curly Cable 28AWG 13C OD60mm VW1 Matt Black L300mm 80C 30V
Brand: WCH Cable
Price: 0.2512 USD

Wholesale UL21686 TPU Curly Cable 28AWG 13C OD6.0mm VW-1 Matt Black L=300mm 80C 30V from china suppliers

Brand Name : WCH Cable

Model Number : UL21686

Certification : UL Certificate

Place of Origin : Dongguan, China

MOQ : 100 PCS

Price : USD0.2512

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100,000pcs per month

Delivery Time : 9 days for ready goods

Packaging Details : 200pcs per carton

Rated Voltage : Low Voltage 30V

Jacket Material : Extruded TPU

Product Name : Curly Cable

UL Style : UL21686

Curly Segment : 300mm

Colour : Matt Black

Conductor Gauge : 28AWG

Jacket Thickness : 15 Mils minimum

Contact Now

UL21686 TPU Curly Cable 28AWG 13C OD6.0mm VW-1 Matt Black L=300mm 80C 30V

TPU Curly Cable is the most featured product of WCH Cable. Fast resilience, easy working, long flex life, are the outstanding characteristic of WCH Cable tpu curly cable. Below is one of the example. More custom item or designated properties, please contact WCH Cable staff to get it.

Spiral coiling diagram:

UL21686 TPU Curly Cable 28AWG 13C OD6.0mm VW-1 Matt Black L=300mm 80C 30V

Product parameters:

Spiral Cable Construction	Spiral Length (unexpanded)	(mm)	300
	Straight Ends	(mm/mm)	200/200
	Extension Ratio		1 : 4
	Spiral Outer Ø	(mm)	25
	Tail Angle		90 degree
	End Treatment		Cut Flat
Electrical Capability	Working Voltage	(V)	30
	Temp Range	(°C)	-40 to +80
	Test Voltage	(V)	2000/3000
	Nominal Voltage	(V)	30
	Conductor Resistance	(Ω/KM 20°C)	239
	Insulation Resistance	(MΩ/KM 20°C)	100
Standard & Use	UL Marking		Per UL21686
	CUL Standard		I/II A
	Flammability		VW-1, FT1
Raw Cable Construction	Conductor Size	(AWG)	28
	Insulation Material		PP (RoHS)
	Insulation Diameter	(mm)	0.90
	Conductor Quantity		13 Cores
	Assembly		Stranded in layers
	Overall Diameter	(mm)	6.00
	Jacket Material		Extruded TPU (RoHS)
	Surface Effect		Matt Black

UL21686 TPU Sheathed Cable 80C 30V

Style Number	Core Quantity	Conductor Size	Conductor Strands	Insulation Thickness	Insulation Diameter	Jacket Thickness	Overall Diameter	Conductor Resistance
Style Number	Core Quantity	AWG	No/mm	mm	mm	mm	mm	Ω/KM
UL21686	2C	30	7/0.100	0.23	0.80	0.38	3.20	381.00
	2C	28	7/0.127	0.23	0.90	0.38	3.40	239.00
	2C	26	7/0.16	0.23	1.00	0.38	3.60	150.00
	2C	24	11/0.16	0.23	1.10	0.38	3.80	94.20
	2C	22	17/0.16	0.23	1.30	0.38	4.20	59.40
	2C	20	21/0.178	0.23	1.50	0.38	4.60	36.70
	2C	18	34/0.178	0.23	1.80	0.38	5.20	23.20
	2C	16	26/0.25	0.23	2.00	0.38	5.80	14.60
	3C	30	7/0.100	0.23	0.80	0.38	3.40	381.00
	3C	28	7/0.127	0.23	0.90	0.38	3.50	239.00
	3C	26	7/0.16	0.23	1.00	0.38	3.80	150.00
	3C	24	11/0.16	0.23	1.10	0.38	4.00	94.20
	3C	22	17/0.16	0.23	1.30	0.38	4.40	59.40
	3C	20	21/0.178	0.23	1.50	0.38	4.80	36.70
	3C	18	34/0.178	0.23	1.80	0.38	5.50	23.20
	4C	30	7/0.100	0.23	0.80	0.38	4.80	381.00
	4C	28	7/0.127	0.23	0.90	0.38	5.10	239.00
	4C	26	7/0.16	0.23	1.00	0.38	5.30	150.00
	4C	24	11/0.16	0.23	1.10	0.38	5.50	94.20
	4C	22	17/0.16	0.23	1.30	0.38	6.00	59.40
	4C	20	21/0.178	0.23	1.50	0.38	6.50	36.70
	5C	30	7/0.100	0.23	0.80	0.38	5.00	381.00
	5C	28	7/0.127	0.23	0.90	0.38	5.30	239.00
	5C	26	7/0.16	0.23	1.00	0.38	5.60	150.00
	5C	24	11/0.16	0.23	1.10	0.38	5.80	94.20
	5C	22	17/0.16	0.23	1.30	0.38	6.40	59.40
	6C	30	7/0.100	0.23	0.80	0.38	5.30	381.00
	6C	28	7/0.127	0.23	0.90	0.38	5.60	239.00
	6C	26	7/0.16	0.23	1.00	0.38	5.90	150.00
	6C	24	11/0.16	0.23	1.10	0.38	6.20	94.20

WCH Cable - Professional Manufacturer of Curly cable, Curly cord, PUR cable, TPE cable

UL21686 TPU Curly Cable 28AWG 13C OD6.0mm VW-1 Matt Black L=300mm 80C 30V

Tag: UL21686, tpu cable, curly cable
